Screw Capping Machine FH-SCM008

The height of the cover wheel can be adjusted, the distance between the two sides of the bottle can be adjusted, the clamping degree of the four sets of cap screws can be adjusted, and the scale is installed with the scale to make the adjustment more convenient and more accurate.

Product Description

●Advanced man-machine interface operating system, operating parameters can be stored and adjusted, fault prompts, easy to use.

●Eight-wheeled cap in motion, the capping speed is fast, and it can effectively prevent the anti-theft cap from breaking and damage to the cap.

●The height of the cover wheel can be adjusted, the distance between the two sides of the bottle can be adjusted, the clamping degree of the four sets of cap screws can be adjusted, and the scale is installed with the scale to make the adjustment more convenient and more accurate;

●The capping rate is high, the speed is fast, etc. When the product is replaced, it is only necessary to adjust the height and width of the cap wheel slightly; the adjustment is simple, convenient and practical.


Technical Parameters:
1.Capping speed:80-100bottles/min

2.Cap diameter:80-100mm(customized)

3.Bottle diameter:80-130mm(customized)

4.Bottle height:100-250mm(customized)

5.working pressure:0.4-0.6MPa

6.Power:1500W

7.Power supply:220V 50/60Hz

8.Weight:200kg

9.Size:1200*900*1670mm
