Semi Automatic Glass Jar Vacuum Capping Machine FH-SVC15

It adopts PLC control system and touch screen interface operation, which is extremely simple and clear to use

●The vacuum pressure can be adjusted on the touch screen

●The contact material is food-grade silica gel

Reasonable and stable structure, easy and quick to change different tank types

Good airtightness to ensure the qualified rate of the product


Product Description

This semi automatic glass jar vacuum capping machine is new developed equipment, it is a domestic original. It sets the automatic glass jar vacuum and put cover in one, the hand glass jar vacuum pump way, can get a high degree glass bottle vacuum. It is widely used in the industries of food canning, beverage, condiment, health care and other industries. The semi automatic glass jar vacuum capping machine has the function of automatic capping, no bottle no capping, automatic alarm when no cap, stable and reliable performance.


Features:

1) This semi automatic glass jar vacuum capping machine is composed of the turntable, vacuum-pumping system, cap screwing structure and electric cabinet with easy operation;

1. This semi automatic glass jar vacuum capping machine is reasonable and stable structure, convenient and quick to change molds;

2. This semi automatic glass jar vacuum capping machine is excellent sealing performance to ensure the qualified rate of the product (vacuum degree can reach -0.08Mpa);

3. It is necessary to press the button with both hands at the same time to trigger the equipment action, and the operation is safe;

4. This semi automatic glass jar vacuum capping machine has Servo screw cap, adjustable torque; the contact material is food-grade silica gel, which does not damage the lid;

5. It adopts PLC control system and touch screen interface operation, which is extremely simple and clear to use; the vacuum pressure can be adjusted on the touch screen. Real time

The vacuum pressure is displayed graphically on the touch screen, which is simple and intuitive.

6. The electrical and pneumatic components of the whole machine are made of well-known manufacturers at home and abroad, with reliable and stable quality;


Technical Parameters:

1. Applicable bottle cap range: ∅20-∅100mm

2. Applicable bottle height range: ∅30-∅200mm; (different bottle size and height needs to change the mold)

3. Production capacity: 10-15 bottles/hour;

4. Power of the whole machine: 1.2KW;

5. Power supply: 220V/50HZ;

6. Air pressure: 0.5-0.8MPa.

7. Vacuum degree: up to -0.07MPa.

8. Equipment size: 750MMX650MMX1500MM.
